The LUMOtech SERIES L05020 is a compact, non-dimmable constant current LED driver with a maximum output power of 12W.

The driver features two separate output currents of 350mA and 700mA, with only one output used at a time. This makes it suitable for various LED modules and recessed spotlights that require a constant current power supply.

With a maximum output power of 12W and a choice of 350mA or 700mA output current, this LED driver is suitable for a wide range of applications, including cabinet lighting, recessed spotlights and other professional LED lighting installations.

A constant current LED driver regulates the electrical current supplied to the connected LED module. This ensures that the LED receives the correct current, provided that the selected output current and voltage range match the specifications of the LED module.

The LUMOtech L05020 is suitable as a replacement driver or for new installations where the electrical specifications are compatible.

Important: This LED driver is non-dimmable and is not suitable for use with an LED dimmer.

Technical Specifications

• Brand: LUMOtech

• Series: SERIES

• Article number: L05020

• Type: Constant Current (CC) LED Driver

• Output current: 350mA or 700mA

• Maximum output power: 12W

• Application: LED modules and LED lighting fixtures

• Dimmable: No – Non-Dimmable
