SELF Electronics LED Power Supply dimmable SLD15-700IL-Es 700mA 15.4W
Flicker free dimmable LED power supply in a plastic housing IP20 15W 700mA constant current. These SELV compliant devices are suitable for LED lighting applications and are protected against overload, overvoltage, overtemperature as well as short circuit. They are dimmable 10-100% and comply with EN55015, EN61347-1 as well as EN61347-2-13.
- dimensions: 85,3x41x22mm
- Voltage In (Vac): 220~240
- Voltage Out (Vdc): 9-22
- Intensidad Out (A): 0.35
- Frecuency (Hz): 50~60
- Power (W): 6.3-15.4W
- operating temperature: -25 to +50°C
- Critical Temperature (°C): 85
- Ingress Protection: IP20
- Dimmable: Phase leading-edge or trailing-edge
- Power factor: 0.95
- data sheet
